Basic Front Panel and IR Remote Operation

Basic Routing

Setting a route using the front panel of the matrix will route the input signal to the selected output.
To set a route using the front panel of the INT-44HDX:
1. Press the desired input button (source).
2. Press the desired output button (display).
3. Press the TAKE button. All the selected buttons will flash then go dark indicating a routing change.

Advanced Routing

One to Many Outputs

To route video and audio from input 2 to outputs 1 and 4:
1. Press input 2.
2. Press output 1, then output 4.
3. Press ENTER.

One to All Outputs

To route video and audio from input 3 to all outputs:
1. Press input 3.
2. Press ALL.
3. Press ENTER.
