User Login

Open a web browser and go to the IP address of the INT-44HDX. The default IP address is 192.168.0.178.
Type user in the Username field.
Enter the password to gain control of the matrix. The default password is "user".
Press the Enter key on your keyboard or tablet to go to the matrix control screen.

Matrix Routing - User

Click the input to output route and the button will turn green once the route has been changed.

Web Browser Control

Username:
Password:
Output1 Output2
Input1
Input2
Input
Input3
Input4
INT-44HDX
Login
INT-44HDX
Output
Output3 Output4
INT-44HDX
Installation Guide
19
