Connect IR Control

The INT-44HDX features IR input connections for the remote devices connected to the HDBaseT inputs, IR input
connections for the remote displays connected to the HDBaseT outputs, an IR input connection to control all
remote HDBaseT devices, and an IR input connection to control the matrix. For remote displays that require IR
control, Intelix recommends using the DIGI-HD60C-R or DIGI-HDX-R.
Only use the included IR receiver or the IR-AC IR adapter cable (sold separately) with the INT-44HDX4. The IR
adapter cables allow third party controllers to connect directly to the IR input ports of the INT-44HDX. If addition
IR receivers are required, the DIGIB-EYE is a compatible substitute. Third party 12V DC IR components are not
compatible with the INT-44HDX.

Remote Display Control via IR

An IR signal passed directly from the matrix location or from a third party control system can provide control of the
display device through the HDBaseT connection.
Insert a compatible IR receiver into the IR input port (IR IN) of the matrix for the display device to control.

Global Control via IR

An IR signal passed directly from the matrix location or from a third party control system can provide control of all
display devices through the HDBaseT connections.
Insert a compatible IR receiver into the IR input port (IR ALL IN) of the matrix to control all remote devices.

Concealed Matrix Control via IR

When the INT-44HDX is installed in an equipment rack or other concealed location, access to the front panel for
normal IR control may be difficult. The IR EYE input allows the IR remote to control the matrix.
Insert a compatible IR receiver into the IR input port (IR EYE) of the matrix.
INT-44HDX
Installation Guide
13
