INSTALLING THE PISTOL GRIP

This contoured pistol grip enables intuitive trigger-and-scan operation, which is very
helpful in scan intensive applications.
When a pistol grip is necessary, install it to the mobile computer by following these
steps:
1) Press for the mobile computer to enter suspend mode.
2) Place the mobile computer face down on a flat and clean surface.
3) Remove the hand strap as well as the side plates as shown below.
4) Connect the power connector from the pistol grip to the receptacle on the
mobile computer.
5) Screw the pistol grip to the back of the mobile computer.
6) Make sure all screws are tightened up.
7) Turn on the mobile computer to test the trigger.
