UNDERSTANDING THE ICONS ON THE TASKBAR
ICON DESCRIPTION
The USB connection for ActiveSync operation is successfully
established.
Double-tap it to view status. Tap [Disconnect] if
necessary.
The Bluetooth PAN connection fails. (= disconnected)
The Bluetooth PAN connection is successfully established
through the Bluetooth Manager utility.
Double-tap it to view or renew IP Information.
It provides control of the power to the 802.11b/g modules.
Double-tap any of these icons to configure the power
setting.
It indicates the Wi-Fi module (802.11b) is enabled.
See WLAN1 status icons
The Wi-Fi connection fails. (= disconnected)
Double-tap it to access the Wireless Information tab for
establishing a new connection.
The Wi-Fi connection is successfully established.
Double-tap it to view or renew IP & Wireless Information.
It provides access to the Bluetooth services.
Initially, you need to go to Start > Programs >
BTManager to open the Bluetooth Manager so that this
icon will appear on the taskbar.
It provides access to the Reader Configuration Utility.
Initially, you need to double -tap the ReaderConfig
shortcut on the desktop so that this icon will appear on
the taskbar.
Tap it to change the input method.
Tap it to switch to desktop or any task, such as a running
program or window.
It indicates the battery status. The other icons are
.
Chapter 2
below.
SEE ALSO
3.2.1 USB
Connection (via
cradle)
3.2.4 BTPAN
4.1 Wireless
Power Manager
3.2.3 WLAN
4.2 Bluetooth
Manager
Software Input
Panel (SIP)
Switch Task
1.1.3
Understanding
the Battery icons
