TERMINAL
Model Name: M0010
Version 1.00

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the M0010 and is the answer not in the manual?

Questions and answers

Related Manuals for CipherLab M0010

Summary of Contents for CipherLab M0010

  • Page 1 TERMINAL Model Name: M0010 Version 1.00...
  • Page 2 Due to continued product development this information may change without notice. The information and intellectual property contained herein is confidential between CIPHERLAB and the client and remains the exclusive property of CIPHERLAB CO., LTD. If you find any problems in the documentation, please report them to us in writing.

  • Page 3: Safety Precautions

    DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS The use of any batteries or charging devices, which are not originally sold or manufactured by CipherLab, will void your warranty and may cause damage to human body or the product itself.

  • Page 4: Care & Maintenance

    This laser component emits FDA / IEC Class 2 laser light at the exit port. Do not stare into beam. CARE & MAINTENANCE This mobile computer is intended for industrial use. The mobile computer is rated IP 64, however, it may do damage to the mobile computer when being exposed to extreme temperatures or soaked wet.

  • Page 5: Release Notes

    RELEASE NOTES VERSION DATE NOTES 1.00 Aug. 10, Initial release 2007...

  • Page 7: Table Of Contents

    CONTENTS IMPORTANT NOTICES ......................3 FCC Regulations........................3 Safety Precautions .........................3 Care & Maintenance......................4 RELEASE NOTES........................5 INTRODUCTION ........................1 Getting Familiarized with 9400.....................2 Installing the Hand Strap....................3 Installing the Pistol Grip.....................4 Dimensions ..........................6 Features ...........................6 Inside the Package........................8 Accessories ..........................8 USING THE TERMINAL ......................9 1.1 Battery..........................9 1.1.1 Inserting the Battery....................10 1.1.2 Charging the Battery ....................12...
  • Page 8 9400 Mobile Computer Reference Manual 1.7 Communications ......................26 1.7.1 Using the Cradle ....................26 1.7.2 Inserting the SIM Card ...................28 1.7.3 Turn off the Wireless Networks................29 1.7.4 Using the Headset....................29 LEARNING WINDOWS CE BASICS ..................31 2.1 Getting Started ......................31 2.1.1 Desktop........................33 2.1.2 Taskbar........................34 2.1.3 Start Menu.......................36 2.1.4 Input Methods ......................37...
  • Page 9 Terminal Reference Manual 4.3.2 RFID Reader Settings .....................81 4.3.3 Data Output ......................82 4.3.4 Beeper / Vibrator ....................84 4.3.5 Symbology Settings ....................84 4.4 Inbox ..........................84 4.4.1 Creating an E-mail Box ..................85 4.4.2 Synchronizing Inbox....................88 4.5 Backup Utility ........................89 4.5.1 Managing the Registry..................90 4.5.2 Getting Ready for Backing up Files ..............92 4.5.3 Backing up Files......................93 4.5.4 Using Backups for Restore ..................94...

  • Page 11: Introduction

    We recommend you to keep one copy of the manual at hand for quick reference or maintenance purposes. To avoid any improper disposal or operation, please read the manual thoroughly before use. Thank you for choosing CipherLab products!

  • Page 12: Getting Familiarized With 9400

    Terminal Reference Manual GETTING FAMILIARIZED WITH TERMINAL Figure 1: Front / Back View...

  • Page 13: Important Notices

    INSTALLING THE HAND STRAP The hand strap is ideal for one-handed operation, which requires safe and convenient hold of the mobile computer. Warning: Always make sure the hand strap is well hooked and screwed to the back of the mobile computer before use. When the hand strap is desired, install it to the mobile computer by following these steps: 1) Place the mobile computer face down on a flat and clean surface.

  • Page 14: Installing The Pistol Grip

    Terminal Reference Manual INSTALLING THE PISTOL GRIP This contoured pistol grip enables intuitive trigger-and-scan operation, which is very helpful in scan intensive applications. When a pistol grip is necessary, install it to the mobile computer by following these steps: 1) Press for the mobile computer to enter suspend mode.
  • Page 15 Figure 3: Installing the Pistol Grip...

  • Page 16: Dimensions

    Terminal Reference Manual DIMENSIONS Figure 4: Dimensions FEATURES Ergonomic design - ruggedized yet streamlined, with hand strap for secure hold. Built tough to survive drop test and sealed against moisture/dust to industrial standard IP 64. Microsoft Windows CE 5.0 operating system, 520 MHz Intel PXA270 processor 128 MB non-volatile NAND flash memory to store OS and software programs (part of the free space is used as a storage card called DiskOnChip)
  • Page 17 64 MB / 128 MB SDRAM to store and run programs, as well as store program data One miniSD expansion slot for memory card Dual mode support - One scan engine (integrated barcode scanner/imager) plus one RFID reader Total wireless solution - connectivity includes Bluetooth and 802.11b/g . A 3.5"...

  • Page 18: Inside The Package

    Terminal Reference Manual Programming support includes Reader DLL and System API. Accessories and peripherals include pistol grip, international AC charging cradle, etc. INSIDE THE PACKAGE The following items are included in the package. Save the box and packaging material for future use in case you need to store or ship the mobile computer. Terminalr Rechargeable Li-ion battery pack Stylus...

  • Page 19: Using The Terminal

    Chapter 1 USING THE TERMINAL This chapter explains the features and usage of the terminal. IN THIS CHAPTER 1.1 Battery ..................9 1.2 Memory ..................15 1.3 Keypad..................18 1.4 Touch Screen................21 1.5 Notifications................24 1.6 Data Capture................26 1.7 Communications ..............

  • Page 20: Inserting The Battery

    Terminal Reference Manual 1.1.1 INSERTING THE BATTERY When you first receive the package, the rechargeable functionality of the backup battery is turned off. It is controlled by a DIP switch inside the battery compartment as shown below. For shipping and storage purposes, save the mobile computer and the main battery in separate packages, and adjust the DIP switch to the OFF position (bottom).
  • Page 21 Chapter 1 3) Hold the mobile computer still and press the release button to unlock the battery cover. 4) Slide off the battery cover. 5) Use the stylus (or a sharp-pointed object, such as a pencil) to adjust the DIP switch to the ON position (top).

  • Page 22: Charging The Battery

    Terminal Reference Manual 1.1.2 CHARGING THE BATTERY The main and backup batteries may not be charged to full for shipment. When you first receive the package, you will need to charge batteries to full before using the mobile computer. Note: To charge the batteries to full, it requires approximately 8 hours for the first time. After the initial charging, it takes only 4 hours to charge the batteries to full.

  • Page 23: Understanding The Battery Icons

    Chapter 1 1.1.3 UNDERSTANDING THE BATTERY ICONS The battery pack is the only power source for the mobile computer to work. It also charges the backup battery on the main board so that the data stored in SRAM can be retained properly. Therefore, when the main battery charge goes low (see below for battery status icon), you need to replace the battery pack with a charged one or charge it as soon as possible.
  • Page 24 Terminal Reference Manual Stop wireless connectivity, Bluetooth, or 802.11b that is not in use. Refer to the Wireless Power Manager. To save power, go to Start > Settings > Control Panel and select Display (for backlight settings) or select Power (for power schemes). Warning: Using backlight, wireless connectivity, and peripherals while on battery power will substantially reduce battery life.

  • Page 25: Memory

    Chapter 1 1.2 MEMORY Read-only Memory (ROM) 128 megabytes flash memory for storing OS (Windows CE 5.0) and custom application programs. Yet a small portion of the memory is referred to as DiskOnChip, which can store data and programs that you wish to retain even after a hardware reset.
  • Page 26 Terminal Reference Manual SDRAM STORAGE MEMORY (LEFT) PROGRAM MEMORY (RIGHT) 64 MB / 128 MB It refers to the memory It refers to the memory onboard allocated for file and data allocated for running storage. programs. (DESKTOP) MY DEVICE > DISKONCHIP The DiskOnChip is part of the onboard 128 MB flash memory.

  • Page 27: Inserting The Minisd Card

    Chapter 1 START > SETTINGS > CONTROL PANEL AND DOUBLE-TAP THE STORAGE MANAGER ICON Here provides a tool for administrators to reformat the DiskOnChip folder or storage card (miniSD). Warning: This tool is for the use of system administrators only. Everything on the storage device will be permanently erased after reformatting.

  • Page 28: Keypad

    Terminal Reference Manual Figure 6: Inserting the miniSD Card REMOVING THE MINISD CARD If you wish to remove the miniSD card, simply push the card after removing the side plate. The miniSD card will be rejected automatically. 1.3 KEYPAD Silicon rubber has been chosen for their durability and prompt feedback. The 28-key keypad includes alphanumeric, navigation, function keys, and so on.

  • Page 29: Using The Keypad

    Chapter 1 Figure 7: 28-key Layout Note: Functionality of keys is application-dependent. 1.3.1 USING THE KEYPAD PRESS FIRST, AND THEN The LED backlight of keypad is turned off by default. It can be toggled ON/OFF by the key combination: [Func] + [0]. START >...

  • Page 30: Function Key

    Terminal Reference Manual 1.3.3 FUNCTION KEY The [Func] (function) key serves as a modifier key. 1) To enable this modifier key, press on the keypad. A circular icon of the letter "F" will appear on the status bar. This modifier key is hold down as long as the icon is displayed.

  • Page 31: Programmable Keys

    Chapter 1 1.3.4 PROGRAMMABLE KEYS Two user-definable keys, named P1 and P2, are provided on the keypad. Together with the SCAN key as well as the four side triggers on each side of the touch screen, they can be re-defined as another key or to serve as a shortcut key for launching a specific program.

  • Page 32: Adjusting The Backlight

    Terminal Reference Manual The LED backlight of screen, which helps ease reading under dim environments, can be controlled manually and automatically. Warning: Using backlight while on battery power will substantially reduce battery life. It is suggested to dim the backlight while working in a well-lit area or automatically turn off the mobile computer when not in use.
  • Page 33 Chapter 1 3) Tap the [Advanced] button (right above). 4) In the Settings tab, you can select the luminosity of backlight when it is set to be automatically turned on by pressing any key or tapping the screen. Tap, hold, and drag the slider for AC and battery powered respectively.

  • Page 34: Re-Calibrating The Screen

    Terminal Reference Manual 1.4.2 RE-CALIBRATING THE SCREEN This LCD is also a touch screen that can be calibrated through screen alignment. START > SETTINGS > CONTROL PANEL AND DOUBLE-TAP THE STYLUS ICON Tap the Calibration tab, and then tap the [Recalibrate] button. Warning: DO NOT use any pointed or sharp objects to move against the surface of the screen.

  • Page 35: Audio

    Chapter 1 Charging done Good Read Bluetooth enabled Note: The green LED is also used for "Good Read" while collecting data. 1.5.2 AUDIO Speaker The mobile computer is integrated with a mono speaker, a low power transducer type, used for playing sounds applied to events in Windows and programs, as well as playing audio files such as .WAV files.

  • Page 36: Vibrator

    Terminal Reference Manual 1.5.3 VIBRATOR The mobile computer is integrated with a vibrator, which is software programmable for feedback. This can be helpful when working in noisy environments. 1.6 DATA CAPTURE 1.6.1 BARCODE & RFID READER A wide variety of scan engines is available for delivering flexibility to meet different requirements.
  • Page 37 Chapter 1 4) The cradle is ready for charging. 5) Seat the mobile computer in the cradle. If data communications are desired at the same time, you can establish a proper connection with a computer or remote host. For example, you may establish a USB connection for ActiveSync.

  • Page 38: Inserting The Sim Card

    Terminal Reference Manual Figure 8: Understanding the Cradle 1.7.2 INSERTING THE SIM CARD 1) Press for the mobile computer to enter suspend mode. 2) Hold the mobile computer still and remove the hand strap as well as the battery. 3) Use your finger to slide the locking plate towards its hinge to unlock the SIM card holder.

  • Page 39: Turn Off The Wireless Networks

    Chapter 1 Figure 9: Inserting the SIM Card 4) Flip up the SIM card holder. 5) Insert the SIM card to the SIM card holder, using the card orientation shown below. 6) Push the SIM card holder down. 7) Slide the locking plate away from its hinge to secure the SIM card holder. 1.7.3 TURN OFF THE WIRELESS NETWORKS The mobile computer supports state-of-the-art wireless technologies, Bluetooth and 802.11b/g, so that it is able to send/receive data in real time in an efficient way.
  • Page 40 Terminal Reference Manual...

  • Page 41: Learning Windows Ce Basics

    Chapter 2 LEARNING WINDOWS CE BASICS This chapter mainly describes the basic skills to work with the terminal. The add-on utilities for applications regarding data collection, processing, and transmission, are introduced in the following chapters. The terminal is specifically designed for real-time data collection in the Windows CE 5.0 environment.
  • Page 42 Terminal Reference Manual SUSPEND MODE Like your PDA, Pocket PC and most handheld devices, the terminal functions when it is turned on. This is because the Windows CE operating system eliminates the booting process and runs continuously. Turn On (= Resume from Suspend) To turn on the mobile computer, simply press Turn Off (= Suspend) To turn off the mobile computer, press...

  • Page 43: Desktop

    Chapter 2 2.1.1 DESKTOP The desktop appears when the mobile computer is turned on (left below). Tap and hold anywhere blank on the screen to manage or configure the desktop (right below). Alternatively, you may tap to the right of the taskbar, and then select Desktop.

  • Page 44: Taskbar

    Terminal Reference Manual Note: To customize the desktop, tap anywhere blank on the desktop and select Properties. When you turn on the mobile computer and seat it in the cradle for the first time, you will find these icons displayed on the taskbar. Refer to section 2.1.2 Taskbar for more information on the icons.
  • Page 45 Chapter 2 UNDERSTANDING THE ICONS ON THE TASKBAR ICON DESCRIPTION SEE ALSO The USB connection for ActiveSync operation is successfully 3.2.1 USB established. Connection (via cradle) Double-tap it to view status. Tap [Disconnect] if necessary. The Bluetooth PAN connection fails. (= disconnected) 3.2.4 BTPAN The Bluetooth PAN connection is successfully established through the Bluetooth Manager utility.

  • Page 46: Start Menu

    Terminal Reference Manual It indicates the current input mode of keypad. The other 1.3.4 Alpha Key icons are It indicates the modifier key is enabled. (= function mode) 1.3.5 Function 2.1.3 START MENU Tap the Start button on the taskbar to open the Start Menu.

  • Page 47: Input Methods

    Taskbar and Start Menu. 2.1.4 INPUT METHODS Data entry can be performed by the following methods: Type with the physical keypad. Scan barcode or RFID tag in applications, e.g. WordPad, CipherLab's Application Generator, etc. Tap or write using SIP (Soft Input Panel)

  • Page 48: Finding Out The Capabilities Of Your Mobile Computer

    Terminal Reference Manual USING THE SOFT INPUT PANEL (SIP) Tap the SIP button on the taskbar to select a SIP mode or hide the input panel. In each mode, the characters appear as typed text on the screen. OPTIONS DESCRIPTION Keyboard To type using the virtual keyboard.
  • Page 49 Chapter 2 DEVICE CONFIGURATION CODE The device configuration of terminal is displayed in 5 digits: xxxx-x Take the screenshot of System Properties below for example. Its device configuration is “2410-0”, which means the 28-key mobile computer has equipped with the following parts: A scan engine that employs Laser scan engine Integrated Bluetooth and Wi-Fi modules module...

  • Page 50: Using Activesync

    Terminal Reference Manual 3rd digit RFID module 0= none 1= RFID reader 4th digit Reserved 5th digit Keypad module 0= 28-key 2.3 USING ACTIVESYNC ActiveSync is used to synchronize information between the terminal and your desktop computer, to install programs on the mobile computer, and to backup and restore the mobile computer.

  • Page 51: Add/Remove Programs

    Chapter 2 Connect the USB cable from the cradle's USB device port ( ) to your computer. Connect the power cable from the cradle to a nearby power outlet. Turn on the mobile computer and seat it in the cradle. 2) Your computer will automatically detect the USB device.
  • Page 52 Terminal Reference Manual ALTERNATIVE TO INSTALL NEW PROGRAMS (COPY & PASTE) Alternatively, you may install a new program manually. 1) When connected, open the Microsoft ActiveSync window on your desktop computer. 2) Click the Explorer button from the toolbar. 3) Navigate to the target folder, e.g. the Programs folder, depending on where you wish to access the program.

  • Page 53: Backup/Restore

    Chapter 2 2.3.3 BACKUP/RESTORE To best protect your work, you should regularly back up information on your mobile computer. You can perform a backup by during the ActiveSync operation. The backup file is stored on your desktop computer. 2.4 MANAGING PROGRAMS 2.4.1 QUICK LAUNCH A PROGRAM Tap the Start button to view the Start Menu.
  • Page 54 Terminal Reference Manual If you wish to quick launch a new program, add it to the Programs folder: My Device\Windows\Programs. The program will become available in the Start Menu. To add a new program or subfolder to the Programs folder, you can either use Windows Explorer or ActiveSync.
  • Page 55 Chapter 2 4) Navigate to the Programs folder – My Device\Windows\Programs (right above). 5) Tap and hold anywhere blank on the screen to select [Paste Shortcut] from the pop-up menu. The new program will be added to the Programs folder. 6) Go to Start >...
  • Page 56 Terminal Reference Manual 2) Click the Explorer button from the toolbar. 3) Navigate through file folders to find the program you desire. 4) Right-click the program and select [Create Shortcut] from the pop-up menu. 5) Right-click the shortcut and select [Cut] from the pop-up menu. 6) Navigate to the Programs folder –...

  • Page 57: Create A Folder

    Chapter 2 2.4.2 CREATE A FOLDER USING WINDOWS EXPLORER TO ADD A NEW FOLDER 1) Go to Start > Programs and select Windows Explorer. 2) Navigate through file folders to find where you wish to create a new folder. 3) Right-click anywhere blank on the window and select [New Folder] from the pop-up menu.
