LANCOM GS-1224 and LANCOM GS-1224P
Chapter 4: Operation of Web- based Management
4.3

Monitoring

There are five functions contained in the monitoring function: Detailed Stati-
stics, LACP Status, RSTP Status, IGMP Status and Ping Status.
4.3.1

Detailed Statistics

Displays the detailed counting number of each port's traffic. All counter infor-
mation for one port are shown at one time. Click on a port in the upper screen
to show the values of this port. You can activate up to five receive statistics
and five transmit statistics at the same time. Confirm your selection with a
click on Apply. With Refresh you can update the table.
56
Default community name for Set: private
Default community name for Trap: public
System Event:
Select the events for which an SNMP-Trap should be send (Cold Boot and/
or Warm Boot).
Default: Enable
TP and Fiber Port Event:
Select the events on the ports for which an SNMP-Trap should be send
(Link Up and/or Link Down).
