The Aggregation Configuration displays the current setup of Aggregation
Trunking. With this function you can add a new trunking group or modify the
members of an existing trunking group.
Parameter:
Normal:
Set up the ports that do not join any aggregation trunking group.
Group 1-8:
Groups the ports you choose together. Up to 12 ports can be selected for
each group.
The aggregation groups has to be set up one after each other. Group
I
2 will remain inactive until the ports for group 1 are selected and the
settings are stored with Apply.
4.2.7

LACP

Smart Web Switch supports "Link Aggregation Control Protocol" (LACP). LACP
is a standard network protocol IEEE 802.3ad which dynamically creates and
manages trunk groups.
When you enable LACP link aggregation on a port, the port can automatically
negotiate with the ports at the remote end of a link to establish trunk groups.
LACP also allows port redundancy, that is, if an operational port fails, then one
of the "standby" ports become operational without user intervention.
Parameter:
Protocol Enabled:
Just tick the check box to enable LACP protocol then press Apply.
Key Value:
It's a key for an aggregation. This must be an integer value between 1 and
255 or auto select by switch.
