LANCOM GS-1224 and LANCOM GS-1224P
Chapter 4: Operation of Web- based Management
Rx 1024-Bytes:
Number of 1024-max_length-byte frames in good and bad packets recei-
ved.
Tx 64 Bytes:
Number of 64-byte frames in good and bad packets transmitted.
Tx 65-127 Bytes:
Number of 65 ~ 126-byte frames in good and bad packets transmitted.
Tx 128-255 Bytes:
Number of 127 ~ 255-byte frames in good and bad packets transmitted.
Tx 256-511 Bytes:
Number of 256 ~ 511-byte frames in good and bad packets transmitted.
Tx 512-1023 Bytes:
Number of 512 ~ 1023-byte frames in good and bad packets transmitted.
Tx 1024-Bytes:
Number of 1024-max_length-byte frames in good and bad packets trans-
mitted.
Rx CRC/Alignment:
Number of Alignment errors and CRC error packets received. A cyclic red-
undancy check (CRC) checks an inspection value for data, to detect errors
in the transmitting process and the storage.
Rx Undersize:
Number of short frames (<64 Bytes) with valid CRC.
Rx Oversize:
Number of long frames (according to max_length register) with valid CRC.
Rx Fragments:
Number of short frames (< 64 bytes) with invalid CRC.
Rx Jabber:
Number of long frames (according to max_length register) with invalid
CRC.
Rx Drops:
Frames dropped due to the lack of receiving buffer.
Tx Collisions:
Number of collisions transmitting frames experienced.
