Installation Instructions - Digital Watchdog STAR-LIGHT DWC-V6263TIR User Manual

Installation-
Instructions
1 Detach the camera's cover dome from the
camera's module by unscrewing the four cover
dome screws using the Torx Wrench.
2 Use the camera or mounting template to mark
and drill the necessary holes in the wall or ceiling.
3
Pull wires through and make connections.
4 Using four included screws, mount and
secure the camera to the wall or ceiling.
Secure the camera's cover dome onto the
5
camera base and remove the protecting lm to
complete the installation.
Note : Before you assemble the dome cover, you have to
adjust the direction of shield cover by turning the
dome.
11
