OSD Menu Special (CONT.)
_
MOTION
4
- ALARM :
VIEW TYPE : When motion is detected, select from the following disply options :
1. OFF - Do not display motion alarm
2. ALL - Show all motion zones when motion alarm is detected.
3. BLOCK - Show the area where motion is detected as a solid block.
4. OUTLINE - Show the area where motion is detected as an outline only.
OSD VIEW : If enabled, ALARM will appear on the screen when motion is detected.
ALARM OUT : The camera supports 3.3V alarm output. When motion is detected, an alarm output
can be triggered if enabled.
TIME : Set the dwell time after motion is detected. Values are in seconds.
- DEFAULT : Reset the motion detection settings to their default values.
MOTION
SELECT AREA1
DISPLAY ON
SENSITIVITY ----64
COLOR WHITE
TRANS 0.00
ALARM
DEFAULT
RETURN RET
ALARM
VIEW TYPE ALL
OSD VIEW ON
ALARM OUT ON
TIME ----3
RETURN RET
