Connecting to DVR/Encoder

Use the diagram below to connect to a Universal DVR or Monitor properly.
12VDC
Monitor
- Power Connection - 12vdc Voltage
- All cameras are equipped with a Test video output for on-site con guration.
UNIVERSAL DVR
COAX
Test Video Output
12
