OSD Menu Special (CONT.)
_
DEFECT (CONT.)
8
- BLACK DPC :
1. POS/SIZE : Set the size and position for the DPC Zone.
Use the joystick controller on the camera's board to adjust
the zone's position. Press the enter key and use the joystick
controller to adjust the zone's size.
2. START : Press START to begin the DPC test. The screen will
get bright and compensate for the black defect.
3. DPC VIEW : Show the Defect pixels whichhave been compensated.
4. LEVEL : Set the range of DPC application.
RS485
9
- CAM ID : Set the camera's ID from 0~255.
- ID DISPLAY : Select to show or hide the camera ID on the screen.
- BAUDRATE : Set the camera's baudrate.
Select from : 2400/4800/9600/19200/38400. Default is 9600.
POS/SIZE
START
DPC VIEW
LEVEL
RETURN
CAM ID
ID DISPLAY
BAUDRATE
RETURN
28
BLACK DPC
OFF
----100
RET
RS485
----1
OFF
9600
RET
