Digital Watchdog STAR-LIGHT DWC-V6263TIR User Manual page 24

OSD Menu Special
_
CAM. TITLE
1
Add a name to the camera. Set the title by using the OSD joystick.
D-EFFECT
2
FREEZE Freeze image from the camera at the selected moment.
MIRROR Re ects the caemra : OFF / MIRROR / V-FLIP / ROTATE
NEG. IMAGE Display the camera's view in negative colors.
Mirror OFF
MOTION
3
- SELECT : The camera supports up to 4 seperate motion detection areas. Select which one to adjust.
- DISPLAY : For the selected zone, select ON to adjust its position and size. Use the joystick cotroller
on the camera's board to adjust the zone's position. Press the enter key and use the joystick controller
to adjust the zone's size.
- SENSITIVITY : Set the camera's sensitivity to motion. The higher the value, the more sensitive the camera
is to motion.
- COLOR : Set the color for the motion zone. Select from green, blue, white, or red.
- TRANS : Set the zone's transparency. The lower the number, the more transparent the zone will appear
on the camera's display.
Mirror Flip
24
Rotate
