Adjusting the Camera

Panning 360º
Rotation 360º
Tilting 70º
FOCUS
ZOOM
Focus: Far
Zoom: Tele
Adjusting the camera angle
Adjust the camera angle while the camera is xed on the ceiling.
Pan is used to rotate the camera's body to left and right,
and Tilt is used to adjust the tilt. Rotating the lens by its axis is
called Rotation.
- Panning : 360º
- Rotation : 360º
- Tilting : 70º
Adjusting the camera lens
To adjust the eld of view, turn the zoom screw (-) counter-clockwise
and move it to the left and right to adjust the angle to be xed it by
turning clockwise. (Tele - Zoom in, Wide - Zoom out)
Adjust the focus the same way as described above AFTER the desired
zoom position is established.
Near
Wide
14
