Installation Instructions - Digital Watchdog Star-Light DWC-MC253WT-28 User Manual

Installation-
Instructions
1
Use the camera's mounting template or your
camera to mark the holes as required. Drill into
the drywall and insert the drywall mounts into
the holes.
2
Remove the Security Screw from the Upper
case.
3
Unscrew the upper case from the camera
module by rotataing it couter clock-wise.
4
Mount the camera to the wall using the
included machine screws.
5
Screw the cover dome back by rotating it
clock-wise.
7
Tighten the Security screw back in place to
firmly secure the cover dome to the camera
module.
7
Remove the camera's dome protection cover.
NOTE : When assembling the upper case ring,
press the dome firmly and assemble.
Otherwise, scratches and IR rubber may be
refined and reflections may occur.
