7.1.2 Power cable dimensions (suggested)
Power Supply Cable
Current
mm²
25A (S09)
10
35A (S09)
10
45A (S09)
10
75A (S09)
25
100A (S11)
35
125A (S11)
50
150A (S11)
70
225A (S13)
120
300A (S14)
2 x 70
350A (S14)
2 x 95
400A (S14)
2 x 95
450A (S14)
Bus Bar 30 x 6 mm
500A (S14)
Bus Bar 60 x 4 mm
600A (S14)
Bus Bar 60 x 4 mm
7.1.3 Cable dimensions of the Command Terminals
Maximum connection capacity for all size: 1.5 mm2 (14 AWG)
REVO E-3PH from 25A to 500A
Load Cable (Output)
AWG
mm²
8
10
8
10
8
10
4
25
3
35
1
50
1/0
70
4/0
120
2 x 1/0
2 x 70
2 x 3/0
2 x 95
2 x 3/0
2 x 95
Bus Bar 30 x 6 mm
Bus Bar 60 x 4 mm
Bus Bar 60 x 4 mm
18
AWG
mm²
8
4
8
6
8
6
4
10
3
16
1
16
1/0
16
4/0
25
2 x 1/0
50
2 x 3/0
50
2 x 3/0
50
70
70
70
User's Manual
Earth
AWG
12
10
10
8
6
6
6
4
1
1
1
1/0
1/0
1/0
