7.5

Misc. Configuration (address 04h)

7 6
DIF2 DIF1
7.5.1

Digital Interface Format (DIFX)

Default = 001
Function:
These bits select the digital interface format used for the DAI Serial Port. The required relationship be-
tween the Left/Right clock, serial clock, and serial data is defined by the Digital Interface Format and the
options are detailed in Figures 17 - 22.
DIF2
0
0
0
0
1
1
1
7.5.2

AM Frequency Hopping (AM_FREQ_HOP)

Default = 0
Function:
Enables the modulator to alter the PWM switch timings to remove interference when the desired frequen-
cy from an AM tuner is positioned near the PWM switching rate. The PWM modulator circuitry must first
be powered down using the PDN bit in the Clock Configuration and Power Control (address 02h) Register
before this feature can be enabled. There will be a delay following the power-up sequence due to the re-
locking of the SRC. Once this feature is enabled, the output switch rate is divided by 2.25, resulting in a
lowered PWM switch rate. Care should be taken to ensure that:
PWM_MCLK / 16 > the upper frequency limit of the AM tuner used
7.5.3

Freeze Controls (FREEZE)

Default = 0
Function:
This function will freeze the previous output of, and allow modifications to be made to the Master Volume
Control (address 07h-08h), Channel XX Volume Control (address 09h-12h), and Channel Mute (address
13h) registers without the changes taking effect until the FREEZE bit is disabled. To make multiple chang-
es in these control port registers take effect simultaneously, enable the FREEZE bit, make all register
changes, then disable the FREEZE bit.
DS633F1
5 4
DIF0 RESERVED
DIF1 DIF0
0 0 Left-Justified, up to 24-bit data
0 1 I²S, up to 24-bit data
1 0 Right-Justified, 16-bit data
1 1 Right-Justified, 24-bit data
0 0 One-Line mode #1, 20-bit data
0 1 One-Line mode #2, 24-bit data
1 0 TDM Mode, up to 32-bit data

Table 5. Digital Audio Interface Formats

3 2
AM_FREQ_HOP FREEZE
Description
CS44600
1 0
DEM1 DEM0
Figure
18
17
19
19
20
21
22
