8-Channel Digital Amplifier Controller
Features
> 100 dB Dynamic Range - System Level
< 0.03% THD+N @ 1 W - System Level
32 kHz to 192 kHz Sample Rates
Internal Oscillator Circuit Supports 24.576 MHz
to 54 MHz Crystals
Integrated Sample Rate Converter (SRC)
–
Eliminates Clock Jitter Effects
–
Input Sample Rate Independent Operation
Power Supply Rejection Realtime Feedback
Spread Spectrum Modulation - Reduces EMI
®
PWM Popguard
PS_SYNC
XTI
XTO
SYS_CLK
DAI_MCLK
DAI_SCLK
DAI_LRCK
DAI_SDIN1
DAI_SDIN2
DAI_SDIN3
DAI_SDIN4
MUTE
SCL/CCLK
SDA/CDOUT
AD1/CDIN
AD0/CS
RST
INT
http://www.cirrus.com
for Single-Ended Mode
PWM
Clock
Control
Auto Fs
Detect
DAI
Serial
SRC
Port
2
SPI/I
C Host
Control Port
Copyright © Cirrus Logic, Inc. 2006
Eliminates AM Frequency Interference
Programmable Load Compensation Filters
Support for up to 40 kHz Audio Bandwidth
Digital Volume Control with Soft Ramp
–
+24 to -127 dB in 0.25 dB Steps
Per Channel Programmable Peak Detect and
Limiter
SPI™ and I²C
Separate 2.5 V to 5.0 V Serial Port and Host
Control Port Supplies
Multibit
Volume
Σ∆
/ Limiter
Modulator
Multibit
Volume
Σ∆
/ Limiter
Modulator
Multibit
Volume
Σ∆
/ Limiter
Modulator
Multibit
Volume
Σ∆
/ Limiter
Modulator
(All Rights Reserved)
CS44800
®
Host Control Interfaces
PSR_RESET
Power
PSR_EN
Supply
PSR_MCLK
PSR_SYNC
Rejection
PSR_DATA
PWMOUTA1+
PWM
PWMOUTA1-
PWMOUTB1+
Conversion
PWMOUTB1-
PWMOUTA2+
PWM
PWMOUTA2-
PWMOUTB2+
Conversion
PWMOUTB2-
PWMOUTA3+
PWM
PWMOUTA3-
Conversion
PWMOUTB3+
PWMOUTB3-
PWMOUTA4+
PWM
PWMOUTA4-
Conversion
PWMOUTB4+
PWMOUTB4-
GPIO0
GPIO1
PWM
GPIO2
Backend
GPIO3
Control/
GPIO4
Status
GPIO5
GPIO6
MARCH '06
DS632F1
