SC846 Chassis Manual
Jumper
1-2: Reset
JP35
2-3: Default
1-2: Reset
JP50
2-3: Default
1-2: Reset
JP129
2-3: Default
Fan Jumper Settings
This backplane can use up to four fans. To utilize each fan, you must configure
both jumpers as instructed below.
Jumper
1-2: With fan (default)
JP61
2-3: No fan
1-2: With fan (default)
JP97
2-3: No fan
1-2: With fan (default)
JP62
2-3: No fan
1-2: With fan (default)
JP98
2-3: No fan
1-2: With fan (default)
JP63
2-3: No fan
1-2: With fan (default)
JP99
2-3: No fan
1-2: With fan (default)
JP64
2-3: No fan
1-2: With fan (default)
JP100
2-3:No fan
Jumper Settings
Jumper Settings
Fan Jumper Settings
Jumper Settings
MG 9072 chip reset #1
MG 9072 chip reset #2
MG 9072 chip reset #3
FAN#1
FAN#1
FAN#2
FAN#2
FAN#3
FAN#3
FAN#4
FAN#4
B-8
Note
Note
