SC846 Chassis User's Manual
Supported External HBA to Backplane Cable
Use the following cable if your external HBA has an InfiniBand connector.
Cable Name: SAS EL2/EL1 Cascading Cable (External), 68 cm
Part #: CBL-0166L (SFF-8088 1x to SFF-8088 x1)
Ports: Single or Dual
Placement: External cable
Description: External cascading cable. Connects ports between servers. With most
connectors, use one cable for single port connections and two cables for dual port
connections.
Figure D-10: External Cable (CBL-0166L)
D-16
