4. Place the motherboard in the chassis aligning the permanent and optional
standoffs
5. Secure the motherboard to the chassis using the rounded, Phillips head screws.
Do not exceed eight pounds of torque when tightening down the motherboard.
6. Secure the CPU(s), heatsinks, and other components to the motherboard as
described in the motherboard documentation.
7. Connect the cables between the motherboard, backplane, chassis, front panel,
and power supply, as needed. The fans may be temporarily removed to allow
access to the backplane ports.
Figure 4-11. Secure the Motherboard to the Chassis
Chapter 4: Chassis Setup and Maintenance
Figure 4-10. Motherboard Installation
4-9
