SC846 Chassis Manual
Dual SAS HBA and Cascaded Configuration
SEC_J2
Port B Expander 2
J17
HBA
HBA
Cable 0168L
(internal cable)
SEC_J2
Port B Expander 2
J17
Power Card
SEC_J2
Port B Expander 2
J17
Power Card
Figure C-24: Dual SAS HBA with Cascaded Configuration
IMPORTANT: See Section C-12 of this manual, Failover with RAID Cards and
Multiple HBAs for important information on supported configurations.
PRI_J2
PRI_J1
SEC_J0 SEC_J1
Port A Expander 1
PRI_J2
PRI_J1
SEC_J0 SEC_J1
PRI_J0
Port A Expander 1
PRI_J2
PRI_J1
SEC_J0 SEC_J1
PRI_J0
Port A Expander 1
PRI_J0
Dual Port Cable
Assembly
C-24
Cable 0166L
(External cables)
