Figure 28 continued: Code Update SIL
8
9
10
11
12, 13, 14
15
16
7 of 9
Page
www.DaikinApplied.com
4=Evap MD3
5=Evap DF
6=Not Used
9=INV w/MicroC OA Coil
Damper Type 0=None
1=Single Position 30%
2=Single Position 100%
3=Economizer Airside
4=Economizer Waterside
5=100%OA_D3
6=AirEcon_D3
7=30%_D3
8=EconoAirsideFDD
9=EconFDDD3
OA Flow Station 0=None
1=DF_015-030 (800)
2=DF_036-042 (802)
3=DF_045-075 (047)
4=DF_080-135 (077)
5=Generic Flow Station
6=Generic Flow Station w/CO2
Heating Type 0=None
1=F&BP Control
2=Staged
3=Modulated Gas, 3-1
4=Modulated Gas 20-1
5=Steam or Hot Water
6=SCR Electric
7=MPSLoGas
8=MPSHiGas
Max Heating 1-8 Stages (Default = 1)
Stages
Three Digits (Default = 100)
Max Heat Rise
Supply Fan Type 0=Constant Volume
1=VFD/ABB_BD
2=VFD/DF_BD
3=VFD/MD2_BD
4=VFD/MD3_BD
5=VFD/MD6_BD
6=EBMVAV_DD
7=EBMCAV_DD
8=ABBVAV_DD
9=ABBCAV_DD
Return Fan Type
1=RF_EF VFD/ABB
2=RF_EF VFD/DF
3=RF_EF VFD/MD2
4=RF_EF VFD/MD3
5=RF_EF VFD/MD6
6=PrpEx VFD/ABB
7=PrpEx VFD/DF
8=PrpEx VFD/MD2
9=PrpEx VFD/MD3
A=PrpEx VFD/MD6
B=None
C=1StageExh
D=2StageExh
E=3StageExh
F=EBMVAV_DD
G=EBMCAV_DD
H=ABBVAV_DD
I=Not Used
J=ABBCAV_DD
7=EBM
8=INV
Values 1, 2, 5 & 7
only apply if
Position 1 = 0
(RTU), 2 (MPS), 3
or 4 (DPS)
Value 4 only
applies if Position
1 = 1 (SCU)
0=CAV
