Power supply specifications

CAUTION: Do not mix power supplies with different efficiency and wattage in the chassis. Install only one type of
power supply. Verify that all power supplies have the same part number and label color. The system becomes
unstable and may shut down when it detects mismatched power supplies.
Depending on the installed options, the system is configured with one of the following power supplies:
•

HPE 1600 W Flex Slot Platinum Hot-plug Low Halogen Power Supply

• HPE 1800 W–2200 W Flex Slot Platinum Hot-plug Power Supply
HPE 3000 W 200–277 VAC Platinum Hot-plug Power Supply
•
For more information about the power supply features, specifications, and compatibility, see the Hewlett Packard
Enterprise website.
HPE 1600 W Flex Slot Platinum Hot-plug Low Halogen Power Supply
Specification
Input requirements
Rated input voltage
Rated input frequency
Rated input current
Maximum rated input power
BTUs per hour
Power supply output
Rated steady-state power
Maximum peak power
Value
—
200 VAC to 240 VAC
240 VDC for China only
50 Hz to 60 Hz
8.7 A at 200 VAC
7.2 A at 240 VAC
1734 W at 200 VAC
1725 W at 240 VAC
5918 at 200 VAC
5884 at 240 VAC
—
1600 W at 200 VAC to 240 VAC input
1600 W at 240 VDC input
2200 W for 1 ms (turbo mode) at 200 VAC to 240 VAC
input
96
