a. Loosen the thumbscrew (callout 1).
b. To disengage the access panel from the chassis, slide the panel towards the rear chassis (callout 2).
c. Lift the access panel up and off the chassis (callout 3).
Install the chassis into the rack
Prerequisites
•
Before you perform this procedure, make sure that you have a T-25 Torx screwdriver available.
•
Before you perform this procedure, review the:
◦
Rack warnings and cautions
◦
Server warnings and cautions
Procedure
1. Slide the chassis into the rack until the bezel ears are flushed against the rack columns.
Removal and replacement procedures
32
