Disconnect the tube set

Procedure
1. Power down the server.
2. Push the female connector (jack) to the male connector (plug) for about 1/8 of an inch.
3. Rotate the female connector counter-clockwise until the tube is pushed off the connector by the springs inside.

Remove the server

CAUTION: To avoid accidentally dropping the server, observe the following:
• Always support the bottom of the server when removing and sliding it into the server bay.
• Do not use the release lever as a handle to carry the server.
Procedure
1. Power down the server.
2. Make sure that the server Do not remove LED is off.
