HP HPE Apollo 2000 Gen10 Plus Service Manual page 80

Item Description
2 Node 1 UID button/LED
3 Node 2 Health LED
4 Node 1 Health LED
5 Node 4 Health LED
6 Node 3 Health LED
7 Node 4 UID button/LED
8 Node 3 UID button/LED
Status
Off
1
Solid blue
Flashing blue
Off
1, 2
Solid green
Flashing green
Flashing amber
Flashing red
1, 2
Solid green
Flashing green
Flashing amber
Flashing red
1, 2
Solid green
Flashing green
Flashing amber
Flashing red
1, 2
Solid green
Flashing green
Flashing amber
Flashing red
1
Solid blue
Flashing blue
Off
1
Solid blue
Definition
Deactivated
Activated
• 1 flash per second = Remote management
or firmware upgrade in progress
• 4 flashes per second = iLO manual soft
reboot sequence initiated
• 8 flashes per second = iLO manual hard
reboot sequence in progress
Deactivated
Normal
iLO rebooting
2
System degraded
2
System critical
Normal
iLO rebooting
2
System degraded
2
System critical
Normal
iLO rebooting
2
System degraded
2
System critical
Normal
iLO rebooting
2
System degraded
2
System critical
Activated
• 1 flash per second = Remote management
or firmware upgrade in progress
• 4 flashes per second = iLO manual soft
reboot sequence initiated
• 8 flashes per second = iLO manual hard
reboot sequence in progress
Deactivated
Activated
Component identification
Table Continued
80
