6. Remove the power supply.
To replace the component, reverse the removal procedure.
Removing and replacing a hot-plug drive
CAUTION: To prevent improper cooling and thermal damage, do not operate the system unless all bays are
populated with either a component or a blank.
Procedure
1. Back up all the server data on the drive.
2. Determine the status of the drive from drive LED definition.
3. Press the handle release button (callout 1), and then use the drive handle to pull the drive out of the bay (callout 2).
Removal and replacement procedures
39
