1.2

Understanding external dimensions

• iTM plus adaptor body
1.3

Understanding where terminals and switches are located

Understand the arrangement of terminals and switches on the unit and draw up an effi-
cient work plan. For connection details including the cable type, terminal size, and wiring
precautions, refer to "2. Electric wiring".
1.3.1

Front face

All the terminals used during installation are located on the front face of the iTM plus
adaptor. The power supply terminal is protected with a cover for safety. Remove the screw
to detach the cover.
Besides the terminals, there are several switches and LEDs on the front face of the iTM
plus adaptor.
8
6-5/16
5-1/2
1/4
5/32
Installation Manual 3P291714-4B
DCM601A72 iTM plus adaptor
2-13/32
1/4
5/32
2-13/32
(in.)
