1

Before Installation

Before you start installing the iTM plus adaptor, complete the following checks:
• Check that the iTM plus adaptor comes with all accessories.
• Understand where the terminals and switches of the iTM plus adaptor are located.
• Make sure that an appropriate space for installing the iTM plus adaptor is available.
1.1

Checking that all accessories are included

Based on the following accessory list, check that all accessories for the iTM plus adaptor
are included. If there is any missing or defective part, contact your DAIKIN dealer where
you purchased the product.
<Accessories included with iTM plus adaptor>
A
A
B
C
D
English
a-1
(a-1) iTM plus adaptor body (1 pc.)
(b-1) Round-head wood screw (φ3.5×16), 4 pcs.
(c-1) Clamp, 1 pc.
(d-1) Installation manual (This manual), 1 pc.
Installation Manual 3P291714-4B
DCM601A72 iTM plus adaptor
B
b-1
C
c-1
D
d-1
7
