- Page 1 Installation Manual iTM plus adaptor Model DCM601A72...
- Page 2 Disclosure To the User in USA Part 15 of FCC Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
- Page 3 WARNING • Only qualified personnel must carry out the installation work. • Consult your Daikin dealer regarding relocation and reinstallation of the con- troller. Improper installation work may result in leakage, electric shocks or fire. • Install the controller in accordance with the instructions in the installation man- ual.
- Page 4 Depending on the radio waves, a distance of 3.5 feet (1 meter) may not be sufficient to eliminate the noise. • If water enters inside of the controller, electric shock may be caused and inner electronics may fail. Installation Manual 3P291714-4 English DCM601A72 iTM plus adaptor...
-
Page 5: Table Of Contents
4.1.1 Procedure for a wired remote controller ................ 26 4.1.2 Procedure for a navigation remote controller ..............28 4.1.3 Setting an unique address to each unit (when power distribution is enabled) ....30 English Installation Manual 3P291714-4 DCM601A72 iTM plus adaptor... - Page 6 Quick Operation Guide ..................32 Viewing target area and management point information in list format ........32 Viewing target areas and management points ................ 32 Starting/stopping an area or management point ..............33 Installation Manual 3P291714-4 English DCM601A72 iTM plus adaptor...
-
Page 7: Before Installation
<Accessories included with iTM plus adaptor> (a-1) iTM plus adaptor body (1 pc.) (b-1) Round-head wood screw (φ3.5×16), 4 pcs. (c-1) Cable tie, 1 pc. (d-1) Installation manual (This manual), 1 pc. (d-2) Manual CD, 1 pc. English Installation Manual 3P291714-4 DCM601A72 iTM plus adaptor... -
Page 8: Understanding External Dimensions
Note that only the power terminals are covered with a terminal cover for safety. You can remove this cover by loosening a single screw. In addition to these terminals, several switches and LEDs are also located on the front face of the iTM plus adaptor. Installation Manual 3P291714-4 English DCM601A72 iTM plus adaptor... - Page 9 [DIII] The communication line connection terminals for “DIII-NET”, which enables communications with DAIKIN’s air conditioning equipment. [Di] The terminals for connecting an external signal input device for stopping air con- ditioners in an emergency, or for connecting electric energy meters for calculating the electricity usage of individual indoor air conditioning units.
-
Page 10: Determining Installation Place
• When installing two or more units side by side, they can be arranged without clearance in the horizontal direction. Required installa- tion space 1-9/16 25/32 6-5/16 25/32 1-9/16 25/32 (in.) Wiring duct Installation Manual 3P291714-4 English DCM601A72 iTM plus adaptor... -
Page 11: Environmental Conditions
1.4.3 Environmental conditions The installation environment must meet the following conditions: • Ambient temperature: 14 to 122 °F • Ambient humidity: 85% RH or less (without condensation) English Installation Manual 3P291714-4 DCM601A72 iTM plus adaptor... -
Page 12: Connection
Provide a cable trap before the terminal block and perform wiring to prevent water entry. Water splashing onto the terminal block may result in an electric shock or fire. Terminal block With trap Without trap Installation Manual 3P291714-4 English DCM601A72 iTM plus adaptor... -
Page 13: Connecting Intelligent Touch Manager
2.1.2 Requirements that must be met • Cable type: CPEV or FCPEV cable • Core thickness: AWG22-19 • Cable length: 164 ft. or less in total for overall plus ADP IF wiring English Installation Manual 3P291714-4 DCM601A72 iTM plus adaptor... -
Page 14: Address Setup And Termination Resistor
You must assign a unique address between 2 and 8 for each iTM plus adaptor. Power off the unit once, check and correct the address, and then turn it on again. Check the status of the two LEDs, CPU ALIVE and ALARM. Installation Manual 3P291714-4 English DCM601A72 iTM plus adaptor... -
Page 15: Connecting Diii-Net-Compatible Air Conditioning Equipment
Connecting DIII-NET-compatible air conditioning equipment DIII-NET is a unique air conditioning equipment communication capability developed by DAIKIN. Using DIII-NET, you can centrally control multiple DIII-NET-compatible air condi- tioning devices by connecting them to your intelligent Touch Manager. The iTM plus adaptor allows you to connect additional 64 groups of air conditioners per unit. -
Page 16: Terminals Location And Conceptual Connection Diagram
A maximum of 16 indoor units can be connected per remote controller group. A maximum of 64 remote controller groups (128 indoor units) can be connected. A maximum of 64 indoor units can be connected when power distribution is enabled. Installation Manual 3P291714-4 English DCM601A72 iTM plus adaptor... -
Page 17: Requirements That Must Be Met
Equipment that controls multiple air conditioners is referred to as “centralized controller”. DAIKIN’s product portfolio includes a wide range of centralized controllers suited to differ- ent applications or target sizes, which can be used in combination to construct an optimal air conditioning system. -
Page 18: Connecting Contact Or Pulse Input Equipment Such As Electric Energy Meters
• Do not clamp the cables with high-current lines such as a power cable. NOTE Power distribution is available for a maximum of 64 air conditioners (indoor units) per DIII-NET port. Installation Manual 3P291714-4 English DCM601A72 iTM plus adaptor... -
Page 19: Terminals Location And Conceptual Connection Diagram
• If an instantaneous contact is used for triggering an emergency stop, use one that has an energization time of 200 ms or more. • Do not clamp the cables with high-current lines such as a power cable. English Installation Manual 3P291714-4 DCM601A72 iTM plus adaptor... -
Page 20: Connecting Power Supply
<Connecting power supply> Cable mount Earth leakage breaker Power supply (24VAC, 60Hz) Earth Secure cables with cable ties. Location of cable mount Installation Manual 3P291714-4 English DCM601A72 iTM plus adaptor... -
Page 21: Requirements That Must Be Met
• Do not connect the earth wire to gas or water pipes, lighting rod, or telephone earth wire. • Replace the unit when the unit cannot be turned on due to the blowing of the electrical fuse. English Installation Manual 3P291714-4 DCM601A72 iTM plus adaptor... -
Page 22: Installation
• DIN rail mounting Screw mounting to control enclosure 3.1.1 Dimensions of iTM plus adaptor The figure below shows the dimensions of the iTM plus adaptor. 6-5/16 5-1/2 2-13/32 5/32 5/32 2-13/32 (in.) Installation Manual 3P291714-4 English DCM601A72 iTM plus adaptor... -
Page 23: Installation Procedure
DIN rail mounting The iTM plus adaptor can be mounted to a 1-3/8 in. DIN rail. <Mounting to DIN rail> Do not use screws to secure the iTM plus adaptor onto the DIN rail. English Installation Manual 3P291714-4 DCM601A72 iTM plus adaptor... -
Page 24: Removal From Din Rail
When done, remove the blue protective film from the upper portion of the unit body. 3.2.1 Removal from DIN rail Pull down the lever at the lower portion of the iTM plus adaptor (1) and pull the unit body (2) out toward you. Installation Manual 3P291714-4 English DCM601A72 iTM plus adaptor... -
Page 25: Assigning A Diii-Net Address For Each Air Conditioner
The names of buttons and areas of a navigation remote controller used in this section are shown below. <Navigation Remote controller> Display Up button Menu / Enter button Right button Cancel button Down button English Installation Manual 3P291714-4 DCM601A72 iTM plus adaptor... -
Page 26: Procedure For A Wired Remote Controller
Touch Manager is not communicating with the indoor units normally. Make sure that the cables are connected correctly. 3. Press the Timer ON/OFF button to make the “GROUP” indicator blink. You are now ready to change the DIII-NET address. <Step 3> GROUP SETTING Installation Manual 3P291714-4 English DCM601A72 iTM plus adaptor... - Page 27 The DIII-NET address has been set. <Step 5> GROUP SETTING 6. Press the Inspection/Test Operation button. You are now brought back to the screen shown in Step 6-2. <Step 6-1> GROUP SETTING <Step 6-2> English Installation Manual 3P291714-4 DCM601A72 iTM plus adaptor...
-
Page 28: Procedure For A Navigation Remote Controller
Group No. s e t t i n g Group No. s e t t i n g (Group) Group No. s e t t i n g ( U n i t ) Retur n Setting Installation Manual 3P291714-4 English DCM601A72 iTM plus adaptor... - Page 29 7. Press the Cancel button three times. You are now brought back to the screen shown in Step 7-2. <Step 7-1> Group No. s e t t i n g (Group) Group No 1-03 Retur n Release <Step 7-2> Cool Set temp Room English Installation Manual 3P291714-4 DCM601A72 iTM plus adaptor...
-
Page 30: Setting An Unique Address To Each Unit (When Power Distribution Is Enabled)
Setting an unique address to each unit (when power distribution is enabled) When power distribution is enabled, you need to set a unique address for each unit. For how to set an address, refer to the commissioning manual. Installation Manual 3P291714-4 English DCM601A72 iTM plus adaptor... -
Page 31: Outdoor Unit Address Setup
1 to 127. The default setting is “0”.) 5. Press the BS3 twice to fix the address setting. 6. Press the BS1 button once to return to the normal mode. English Installation Manual 3P291714-4 DCM601A72 iTM plus adaptor... -
Page 32: Quick Operation Guide
Touch the Down button to go to the area being selected and view the areas and management points in it. Touch the Up button to go to the area one level above the current area. Installation Manual 3P291714-4 English DCM601A72 iTM plus adaptor... -
Page 33: Starting/Stopping An Area Or Management Point
(operating) and gray when stopped. When Confirmation Dialog is set to “Enabled” in the system setup, the corresponding message appears. Select the Yes button to confirm the Start/Stop operation. English Installation Manual 3P291714-4 DCM601A72 iTM plus adaptor... - Page 36 3P291714-4 EM11A030 (1203) HT...
