Setting An Unique Address To Each Unit (When Power Proportional Distribution (Option) Is Used) - Daikin iTM plus Installation Manual

5. Using the Up/Down buttons, select the address you want to set.
<Step 5>
6. Press the Menu/OK button.
The indication changes from "Release" to "Set", and the DIII-NET address is set.
<Step 6>
7. Press the Cancel button three times. You are now brought back to the screen shown in
Step 7-2.
<Step 7-1>
<Step 7-2>
4.1.3 Setting an unique address to each unit (when Power Proportional Dis-
tribution (option) is used)
When power distribution is enabled, you need to set a unique address for each unit. For
how to set an address, refer to the Commissioning Manual Supplementary Volume Power
Proportional Distribution (EM11A027).
English
Group Address (Group)
Gr Addr. Release
1-00
Change
Group Address (Group)
Gr Addr. Set
1-03
Release
Group Address (Group)
Gr Addr. Set
1-03
Release
5 35
Thu
P
Cool
Room Set to
82
86
F
F
Installation Manual 3P291714-4B
DCM601A72 iTM plus adaptor
29
