The table below shows the status of the CPU ALIVE/ALARM LED when the iTM plus
adaptor is operating normally or failed.
NOTE
[LED status and operation table]
intelligent Touch Manager and iTM
1.4

Determining installation place

Be sure to install the iTM plus adaptor in a place that meets the conditions described in
1.4.1 to 1.4.3.
1.4.1

Installation place and mounting direction

Below are the description of the installation place and mounting direction. Be sure to
confirm.
• Installation place: Indoor, inside control enclosure (which must be lockable or designed
to be opened only with a special tool)
• Mounting direction: Vertical only
1.4.2

Environmental conditions

Check that the installation environment meets the following conditions:
• Ambient temperature: 14 to 122 °F
• Ambient humidity: 85% RH or less (without condensation)
10
Operating condition
Normal
Hardware failure
Address failure
Communication failure between
plus adaptor
Installation Manual 3P291714-4B
DCM601A72 iTM plus adaptor
CPU ALIVE ALARM
Blink Off
Off On
On On
On Blink
