EUROCOM M375E Service Manual page 31

4. Slide the hard disk assembly in the direction of the arrow
5. Carefully lift the hard disk assembly
-
6. Remove screws in order to separate the cover
3 6
7. Reverse the process to install a new hard disk (pay careful attention to the orientation of the disk under the cover).
a.
b.
All manuals and user guides at all-guides.com
.
1
up out off the computer.
2
from the hard disk
7
c.
1
2
(Figure 3c).
8
4
3
5
7
6
8
Removing the Hard Disk Drive 2 - 7
Disassembly
Figure 3
HDD Assembly
Removal (Cont.)
a. Slide out the HDD as-
sembly.
b. Lift the HDD assembly
out of the bay.
c. Remove the screws and
separate the cover and
HDD.
7. HDD Cover
8. Hard Disk
• 4 Screws
