URBAN WB DC

So, hello!

This manual provides commissioning and use instructions information about URBAN WB DC, which
has been designed and tested to allow electric vehicle charging, specified in IEC 61851.
This document has different sections such as step-by-step installation procedure and technical data.
THE FOLLOWING SYMBOLS ARE USED FOR IMPORTANT
ELECTRIC RISK
Take precautions to make the electrical connection inside the device. Device must be
disconnected from any power source during commissioning.
ATTENTION!
Indicates that the damage to property can occur if appropriate precautions are not taken.
• Compliant with IEC 61851; Electric vehicle conductive charging system (IEC 61851-1 and
IEC 61851-23).
• Compliant with IEC 62196; Plugs, sockets-outlets, vehicle connectors and vehicle inlets-
Conductive charging of electric vehicles
• Directives: 2014/53/UE, Radio and Telecommunication Terminal equipment; 2014/30/UE,
Electromagnetic Compatibility (EMC); 2014/35/UE, Low Voltage.
• Compliant with IEC 61851-24, Digital communication between a DC EV charging station
and an electric vehicle for control of DC charging. Meets the CCS specification, DIN SPEC
70121. ISO 15118 ready.
• Compliant with RoHS 2011/65/EU-2017/2102, Restriction of Hazardous Substances.
Installation Guide
SAFETY INFORMATION IN THIS DOCUMENT
(IEC 62196-1, IEC 62196-2 and IEC 62196-3).
