- Page 1 Link INSTRUCTION MANUAL (M354B01-03-22A)
- Page 2 Link Instruction Manual...
-
Page 3: Disclaimer
CIRCUTOR, SA reserves the right to make modifications to the device or the unit specifications set out in this instruction manual without prior notice. CIRCUTOR, SA on its web site, supplies its customers with the latest versions of the device specifica- tions and the most updated manuals. - Page 4 C O P Y R I G H T I N F O R M AT I O N This document is copyrighted, 2021 by CIRCUTOR, S.A. All rights are reserved. CIRCUTOR, S.A. reserves the right to make improvements to the products described in this manual at any time without notice.
-
Page 5: Table Of Contents
Here’s your manual to use eHome Link Disclaimer ..............................3 Revision log ............................. 3 Here’s your manual to use eHome Link .................... 5 1.- So, hello! ............................6 2.- Overview ............................8 3.- Operating Instructions ........................10 A.- Charging procedure ........................11 B.- Error states .......................... - Page 6 Link This manual provides information about the usability of the eHome Link, which has been designed and tested to allow electric vehicle charging according to IEC 61851-1:2017. This manual contains all the necessary information for a safe use. THE FOLLOWING SYMBOLS ARE USED FOR IMPORTANT...
-
Page 7: So, Hello
• Do not use any adapter, except those where potential risk of explosions are. approved by the EV manufacturer. Adapter only allowed to eHome Link models with • Do not install the Charge Point where falling socket-outlet. objects may damage the equipment. - Page 8 S H O R T D E S C R I P T I O N The Wallbox eHome Link charge point is especially designed to be easily installed in private car parks, both indoors and out, for the purpose of charging every EV model on the market...
-
Page 9: Overview
Link Overview 1. CIRCUTOR Logo 4. Cable + Connector. 2. Status LED bar 5. Frame 3. Front cover 6. Socket-outlet Plugs may vary depending on the model. Instruction Manual... - Page 10 Link Instruction Manual...
-
Page 11: Operating Instructions
1 — G R E E N F I X B A R S TAT U S The eHome Link has a status LED beacon. When it is in green color, it means that the unit is available and ready to start the charge. - Page 12 4 — B L U E D Y N A M I C B L I N K I N G L E D S TAT U S The eHome Link starts the charge process. While charging the EV, the LED light bar will be flashing continuously.
-
Page 13: B Error States
In this last case, the Charge Point starts charging when the operating temperature is reached again. In the following sections it will be explained how the eHome Link indicates the above mentioned errors and the actions taken by the Charge Point. - Page 14 Link 3 — E S TAT E E R R O R This means that there has occurred a communication error between the EV and the Charge Point. If this is the case, the status LED light bar turns into red and flashes in a sequence of two blinks.
- Page 15 Link 7 — M A X I M U M S E L E C T E D O U T P U T C U R R E N T E R R O R If this on-board current limit selection is not set up according to the hardware features, the Charge Point detects it and shows this error.
-
Page 16: Additional Features
G R I D M E T E R R E C O N N E C T I O N F U N C T I O N In the event of the company meter trips out, the eHome Link has an automatic reset function, so it is not necessary for the user to take any action to enable the reset. -
Page 17: Need Help
CIRCUTOR guarantees its products against any manufacturing defect for two years after the delivery of the devices. CIRCUTOR will repair or replace any defective factory product returned during the guar- antee period. • No returns will be accepted and no device will be repaired or replaced if it is not accompanied by a report indicating the defect detected or the reason for the return. - Page 18 CIRCUTOR, S. A. Vial Sant Jordi, s/n 08232 - Viladecavalls (Barcelona) Tel.: (+34) 93 745 29 00 - Fax: (+34) 93 745 29 14 www.circutor.com central@circutor.com...
