Normal Appearance Of Operator Interface Panel - Simplex 4010ES Operator's Manual

LED/Key
Arm/Disarm Keys
Alphanumeric Display
Note: The degree to which you are allowed to control the system depends on the passcode assigned to you. See
the system for details on this.
2.1

Normal Appearance of Operator Interface Panel

The 4010ES operator interface panel shows the following under normal conditions.
• Green power LED is ON - indicating the panel is receiving AC Power
• All other LEDs off.
• Alphanumeric display reports that the system is normal, as shown below.
Note: If the appearance of the operator interface panel is not as shown above, refer to the information in
conditions, and Supervisory conditions
page 5
Table 1: Components of the operator interface
Description
Used with security points. These keys allow you to turn
security devices on (arm) or off (disarm).
Displays text describing abnormal conditions for devices
attached to the panel (i.e., smoke detector in main lobby is in
alarm). Also displays system prompts and messages.
for instructions on managing the alarm, supervisory, or trouble condition.
4010ES Fire Alarm Operator's Manual
Refer To
Advanced functions
Logging in and out of
Alarm Conditions, Trouble
579-969 Rev E
