Chapter 2 — Site Requirements
The following table shows the fully loaded maximum weight of each frame
type.
a. 6D0T means six Drive Bay Assemblies and zero TeraPack Bay Assemblies. 3D3T means three Drive Bay
Data center floors may require reinforcement to hold the library's weight.
Check your site's flooring for load‐bearing specifications.
Spectra Logic is not responsible for damage caused to the library or its
Caution
surroundings if the floor is not adequately reinforced. Inadequate floor
reinforcement can allow the library to sag, causing misalignment of the frames and
robotic motion failures.
Weight-Distribution Plate If you would like to install the library on a
weight‐distributing plate, Spectra Logic recommends a steel plate with the
minimum dimensions of 36 x 30 x 0.25 inches (91.4 x 76.2 x 0.6 cm). Plates
should be placed under the feet at the front and back of each frame
junction and under the outer feet of the right‐most and left‐most frames of
a multi‐frame library.
Flooring Type The floor where the library is to be installed must be level, and
must be hard flooring, such as cement or tile — do not install the library on
carpeting. This requirement is particularly important when installing a multi‐
frame library, because all frames must be precisely aligned. Carpeting also
increases the risk of static discharge when operating the library.
Caution
The library must be installed on a level, hard-surfaced floor such as cement or tile.
A small amount of floor unevenness can be compensated for using the
levelers on each library frame.
March 2015
a
Frame Type
6D0T Main Frame
3D3T Main Frame
6D0T Drive Frame
3D3T Drive Frame
Media Frame
Service Frame
Bulk TAP Service
Frame
Assemblies and three TeraPack Bay Assemblies.
After determining the positions for the plates, attach them to the
Note:
floor to prevent them from moving as you roll the frames into place.
Maximum Weight for LTO
Frame
1574 lb (714 kg)
1461 lb (663 kg)
1561 lb (708 kg)
1447 lb (656 kg)
1227 lb (557 kg)
1000 lb (454 kg)
1087 lb (493 kg)
Site Preparation Guide—Spectra TFinity Library
Physical Requirements
Maximum Weight for
TS11x0 Technology Frame
1641 lb (744 kg)
NA
1627 lb (738 kg)
NA
1180 lb (535 kg)
980 lb (445 kg)
1067 lb (484 kg)
