Chapter 1 — Library Overview
B TAP S
ULK ERVICE
The bulk TeraPack Access Port (bulk TAP) service frame can replace the left
or right service frame. It includes the components of the standard service
frame (see Service Frame Rear Panel Components on page
TAP carousel used to import or export up to 14 magazines in a single
operation.
L C
IBRARY APACITY
The TFinity's modular design makes it possible to increase media capacity or
the number of drives in the library to meet storage and performance needs
as they evolve. The minimum configuration TFinity consists of three frames:
the main frame and two service frames. A mix of media and drive expansion
frames can be added for a maximum total of 40 frames. The frames are
positioned to provide the most efficient configuration based on the site
requirements. The service frames or bulk TAP service frames are always
located at the outside ends of the library.
March 2015
F F
RAME RONT
Figure 4 The front of the bulk TAP media frame.
Site Preparation Guide—Spectra TFinity Library
Bulk TAP Service Frame Front Panel Components
P C
ANEL OMPONENTS
TAP carousel filled
with magazines
Door release
button
Door (open)
14) and a bulk
