Media expansion frames are for media storage only and do not include any
active front or rear panel components.
S F
ERVICE RAME
The library includes two service frames, one for each TeraPorter. The
service frame is the last frame on each end of the library. Figure
the components of the service frame.
Media storage chambers
(behind cover)
Service Expansion
Module (SEM) (optional)
Expansion Power
Module (EPM)
Figure 3 Service frame components (back-side of left-hand service frame shown).
March 2015
F
RAMES
R P C
EAR ANEL
Site Preparation Guide—Spectra TFinity Library
OMPONENTS
Service bay
Media Expansion Frames
3 shows
Service Control
Module (SCM)
Safety door
Storage
Safety door (handle
extended)
Transporter service
access opening
