UBio-X Iris User Guide
4. How to use the terminal
The background image and composition of the basic window can be changed depending
on the administrator's setting. In addition, if the administrator sets the screen saver
time, the LCD screen is turned off automatically if there is no action for set time, and
when the user accessed to the terminal, tried the authentication with fingerprint/card, or
touched the main screen, the LCD screen is automatically activated.
4.1. How to change Auth mode
Select the function key button among Attend [F1], Leave [F2], Out [F3], and In [F4]
button to change the auth mode as you want.
The current auth mode can be checked as the button status below.
If there isn't the selected mode button as <Fig. 4-1>, it is the access mode.
<Fig. 4-1>
69
Card sensing area
