UBio-X Iris User Guide
▶[Port]: The basic port value of the authentication server (UNIS server) is '9870', and if
you change the value, you should change the server program with the same value, so
be cautious.
▶[Terminal ID]: It is a unique ID used for the terminal to distinguish the terminals and
the default value is '1'. It should be the same with the ID of the terminal registered in
the server program and the characters can be set up to 9 digits for maximum.
▶[Wi-Fi]
If you touch the item you want to change,
the keypad appears at the bottom.
If the input is finished with the keypad,
continue the input by touching [
button or the next input window. If you
touch the background window which is
not the input window,
disappears.
If you want to apply the changes, click
[Save] button, and return to the previous
menu by clicking [BACK] button.
When the Wi-Fi dongle is connected to the
USB port on the backward of the device,
this icon [ ] will automatically be
activated as same as left picture.
[Notes]: If you want to apply the Wi-Fi
dongle, you have to purchase it from our
sales team since we cannot guarantee to
cooperate 3 rd party Wi-Fi dongle with our
device.
When the check box [Wireless Enabled]
is checked, the AP list around will be
scanned automatically as the left picture.
If you select the AP name from the AP list,
the AP password will be asked and then
the device will be connected to this AP
when inputting the proper AP password.
If you want to apply the changes, click
[Close] button, and
previous menu by clicking [BACK] button.
41
]
the keypad
return to the
