Union Community UBio-X Iris User Manual page 59

UBio-X Iris User Guide
(2) Errors may occur depending on the type of lighting.
(Errors may occur when incandescent lamps / halogens / quartz / tungsten are installed.)
(3) If there are accessories or obstacles covering your face, errors may occur. (Glasses / Hats /
When the bangs cover the forehead / Headband, etc.)
(4) Please move an object that can reflect infrared rays on the background staring at the product's
sensor. (Glass / Mirror / Metal surface, etc.)
(5) If there are some air conditioners or heaters and etc. in the installed place, errors may occur.
(Errors occur in the case of air conditioners or near blowers for air conditioning in buildings.)
(6) It is recommended to install and operate within the temperature range of 20 to 24 degrees /
10% to 50% humidity.
(7) It is recommended that only one person detects fever at a time.
(8) For accurate temperature measurement, it is recommended to use black body together.
If you select [Terminal] -> [Thermal] in the main screen, the following window appears.
This menu sets the thermal sensor or thermal imaging camera only when you use it.
▶ Display
Select how temperature is displayed in the authentication results window.
- Celsius: Displays the measured temperature in degrees Celsius.
- Fahrenheit: Displays the measured temperature in Fahrenheit.
- None : The temperature is not displayed, only the exothermic detection is indicated.
▶ Temperature around
- Normal: Used for measurements at typical temperatures.
- High: Used to measure temperature in hot places.
- Low: Used to measure temperature in cold place.
▶ Fever temperature
The fever temperature reference is available between 37.0°C and 38.5°C.
If the measured temperature is higher than the exothermic temperature reference, it is
treated as a certification failure
▶ Show thermal
If it is checked(
lower right corner of the main screen.
Click [OK] button to apply the set value, and click [BACK] button to cancel and return.
), displays the Preview image of the thermal imaging camera in the
▶Default setting: Same as left picture
▶Enable ThermalSensor
When checking ( ) this option, you can
use the thermal sensor.
59
