Hisense 43B4E31T Manual

Hisense 43B4E31T Manual

Ip control
Hide thumbs

Advertisement

Quick Links

Download this manual
IP Control Guide
Date
Version No.
9
Sep, 2024
V1.0
th
6
Apr, 2025
V1.1
th
Introduction
This guide provides instructions for setting up and using IP control for Hisense digital signage
displays. IP control allows you to manage these displays over a local area network (LAN) using
TCP/IP network protocols. Commands to control the display are sent in different formats
depending on the product series.
Product Series
Command Format
E series
HEX
BM/GM series
ASCII
DM/GM50D series
HEX
Prerequisites
Stable local area network (LAN) with all devices connected.
•
A computer or control device with IP control software installed.
•
Basic networking knowledge.
•
Ensure all displays and control devices are on the same LAN.
•
Network Setup
Connect all displays and control devices to the same LAN.
•
Assign static IP addresses to displays for stable control access.
•
Check IP addresses via display settings or router interface.
•
Updates
Improved layout for clarity.
Corrected BM/GM series command format to ASCII.
•
Added command format summary table.
•
Clarified command examples for BM/GM series.
•
Improved layout for clarity.
•
Default Port
5000
8088
8000
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the 43B4E31T and is the answer not in the manual?

Questions and answers

Related Manuals for Hisense 43B4E31T

Summary of Contents for Hisense 43B4E31T

  • Page 1 • Introduction This guide provides instructions for setting up and using IP control for Hisense digital signage displays. IP control allows you to manage these displays over a local area network (LAN) using TCP/IP network protocols. Commands to control the display are sent in different formats depending on the product series.
  • Page 2 Understanding IP Control Protocols TCP/IP Protocol: All Hisense displays use TCP/IP for communication. • Command Format: Depends on the series: • E series and DM/GM50D: HEX string commands. BM/GM: ASCII text commands. E series Product Series Android Product Model Firmware Version 43B4E31T FBV02.03...
  • Page 3 Connecting a Client to the IP Control Server Use a client application such as Net Assist (B1). 2. Select “TCP Client” mode. 3. Enter the server IP address and port number. 4. Click “Connect” to establish a connection.

  • Page 4: Command Table

    Command Table Name Set Get Code Example (PC -> HISENSE DISPLAY) Example (HISENSE DISPLAY -> Set Screen Aspect √ 0x3A 0xA6 0x01 0x00 0x00 0x00 0x04 0x01 0x3A data[1] checksum 210100000401000025 Ratio data[1]: FuLL-0x00 Real-0x01 4:3-0x02 14:9-0x03 eg: Aspect Ratio is FuLL A60100000004013A0098 Get Screen Aspect √...
  • Page 5 Name Set Get Code Example (PC -> HISENSE DISPLAY) Example (HISENSE DISPLAY -> of the scheduling pages， bit 3 - bit 0: Page disable-0 Page enable-1 data[2]：Start time hour(0-23) data[3]：Start time minute(0-59) data[4]：End time hour(0-23) data[5]：End time minute(0-59) data[6]：HDMI2-0x06 USB-0x0C HDMI1-0x0D CMS-0x12 Media Player-0x16 Custom-0x18 data[7]：...
  • Page 6 Name Set Get Code Example (PC -> HISENSE DISPLAY) Example (HISENSE DISPLAY -> KEY_FASTFORW ARD KEY_0 0x0B 0xD0 KEY_OK 0x1C KEY_SOURCE 0xFA KEY_ 0x66 KEY_MENU 0xFD KEY_UP 0x67 KEY_INFO 0x0166 KEY_L 0x69 KEY_CMS 0x0305 EF T KEY_R 0x6A KEY_TIME 0x0309 IG HT ex：set volume to 0 - mute...
  • Page 7 2. Setting the Port Number: The default port number for IP control is 8088. If this port is occupied, choose a port between 5000-12000. 3. The IP control server is activated by default when the app is opened. The button will toggle to “Stop”...
  • Page 8 4. Click “Connect” to establish a connection. Command Table Command Command Start Length Command Data Verify End Code Type Code Code Screen on/off On Send DD FF 00 07 C1 31 00 01 BB CC command On Receive AB AB 00 07 C1 31 00 01 CD CD...
  • Page 9 Minute; The third ‘XX’ stands for Second. Reboot the Send DD FF 00 06 C1 1E 00 00 BB CC HISENSE DISPLAY command Receive AB AB 00 06 C1 1E 00 00 CD CD command Power On/Off Power on Send...
  • Page 10 Command Command Start Length Command Data Verify End Code Type Code Code command Mute on Send DD FF 00 07 C1 26 00 00 BB CC command Mute on AB AB 00 07 C1 26 00 00 CD CD Receive command VGA Automatic Send...
  • Page 11 Command Command Start Length Command Data Verify End Code Type Code Code Set Zoom Send DD FF 00 07 C1 3B 00 00 XX 02 stands for Zoom BB CC (811 not support ) command Standard, others stand for Full Screen. Receive AB AB 00 07...
  • Page 12 Command Command Start Length Command Data Verify End Code Type Code Code value of backlight. Set Inquiring Send DD FF 00 06 C1 32 00 01 BB CC Screen On/Off command Receive AB AB 00 07 C1 32 00 01 XX 00 Screen Off, 01 Screen CD CD command...
  • Page 13 Command Command Start Length Command Data Verify End Code Type Code Code setting) Receive AB AB 00 09 C1 3E 00 02 XX Day If 0 is set, Boot Time CD CD command is off. XX Hour XX Minute Set Power Off lime Send DD FF 00 09...
  • Page 14 Command Command Start Length Command Data Verify End Code Type Code Code Movie Mode AB AB 00 07 C1 0F 06 00 CD CD Receive Command Vivid Send DD FF 00 07 C1 0F 06 00 BB CC Command Vivid Receive AB AB 00 07 C1 0F 06 00...
  • Page 15 Product Series Android Product Model Firmware Version 11.0 32DM66D V1.1.0.2-2024021152738 43DM66D V1.1.0.2-2024021152738 50DM66D V1.1.0.2-2024021152738 50DM66E V1.1.0.2-2024021152738 65DM66D V1.1.0.2-2024021152738 75DM66D V1.1.0.2-2024021152738 86DM66D V1.1.0.2-2024021152738 GM50D 11.0 50GM50D V1.1.0.2-2024021152738 55GM50D V1.1.0.2-2024021152738 65GM50D V1.1.0.2-2024021152738 75GM50D V1.1.0.2-2024021152738 86GM50D V1.1.0.2-2024021152738 Series-Specific Instructions Default port: 8000 • Start IP Control app on the display.
  • Page 16 Connecting a Client to the IP Control Server 5. Use a client application such as Net Assist (B1). 6. Select “TCP Client” mode. 7. Enter the server IP address and port number. 8. Click “Connect” to establish a connection.
  • Page 17 Command Table Description Command (HEX Bytes) Example (PC -> HISENSE DISPLAY) HISENSE DISPLAY -> PC Power Off DD FF 00 08 C1 15 00 00 xx AA AA DD FF 00 08 C1 15 00 00 01 AA AA DD BB CC...
  • Page 18 Description Command (HEX Bytes) Example (PC -> HISENSE DISPLAY) HISENSE DISPLAY -> PC PC Input DD FF 00 07 C1 08 00 00 xx 0C yy DDFF0007C1080000010CC3BBCC AB AB 00 07 C1 08 00 00 xx 0C yy BB CC...
  • Page 19 Description Command (HEX Bytes) Example (PC -> HISENSE DISPLAY) HISENSE DISPLAY -> PC Set Contrast DD FF 00 07 C1 37 00 00 xx zz yy ex: set contrast to 32 - zz = 0x20 AB AB 00 07 C1 37 00 00 xx zz yy...
  • Page 20 Description Command (HEX Bytes) Example (PC -> HISENSE DISPLAY) HISENSE DISPLAY -> PC Set Video DD FF 00 09 C1 0A 00 00 xx zz zz ex: vertical 3 devices, horizontal 4 devices, AB AB 00 09 C1 0A 00 00 xx zz zz zz...
  • Page 21 Description Command (HEX Bytes) Example (PC -> HISENSE DISPLAY) HISENSE DISPLAY -> PC LL: when first zz is zz, LL = 08, otherwise, LL = 07 Query DD FF 00 06 C1 36 00 01 xx yy BB DDFF0006C136000101F0BBCC AB AB 00 07 C1 36 00 01 xx zz yy CD...
  • Page 22 Description Command (HEX Bytes) Example (PC -> HISENSE DISPLAY) HISENSE DISPLAY -> PC Query MAC DD FF 00 06 C1 6C 00 00 xx yy BB DDFF0006C16C000001AABBCC AB AB 00 0C C1 6C 00 00 xx zz…zz Address yy CD CD zz .. zz: 6 bytes...

  • Page 23: Testing And Troubleshooting

    Automating Commands and Integrating with Other Systems Write scripts using programming languages like Python to automate hex string • commands. Integrate the Hisense display control into broader home or office automation systems • using compatible software. Testing and Troubleshooting Start with basic commands (Power ON/OFF).

  • Page 24: Security Considerations

    • Conclusion By following this guide, you can effectively manage Hisense digital signage displays over IP control, with reliable command formats tailored to each product series. For further assistance or updates, you may reach our support team by clicking here.
