Error
No 3D image on a con-
nected PC monitor.
No image on additional
2D device.
No image displayed on
the connected TV de-
vice.
No 3D image can be
viewed on the Renfert
2D/3D monitor.
No 3D image is dis-
played on the connected
TV device.
No image displayed on
the connected 2D de-
vice.
10 Technical data
10.1 Head (incl. support arm)
Nominal voltage:
Permissible mains voltage:
Mains frequency:
Power consumption:
Video resolution:
Focus distance:
Magnification:
Approx� illuminance:
Color temperature:
USB memory stick capacity:
Number of storable images, approx�:
Max� video sequence length, approx�:
Max� distance between mounting point of support arm
and screen center:
Action radius of support arm:
Max� table top thickness with universal clamp:
Max� table top thickness with screw mounting:
Weight (incl� support arm):
Weight (Head):
Cause
EASY view 3D HDMI Splitter
• No error!
On EASY view 3D HDMI Splitter,
only 2D images are displayed on
PC monitors�
• 2D device is not fully HD capa-
ble�
• Incorrect device settings�
• No error!
Only EASY view 3D Renfert
2D/3D monitors or PC monitors
can be connected to the HDMI
Splitter�
EASY view 3D Converter 2D/3D
• 2D/3D connections are mixed
up�
• No error!
Only 2D images can be dis-
played on TV devices�
• 2D device is not fully HD capa-
ble�
• Incorrect device settings�
• Incorrect signal input is set on
2D playback device�
• Change EASY view+ 3D to 2D image view�
• If a 3D display required, use a another Renfert 2D/3D moni-
tor (Accessories)�
• Use full HD capable PC monitor�
• Use the Renfert 2D/3D monitor (Accessories)�
• Check 2D device settings (e�g: 1080p60)�
• Use full HD capable PC monitor�
• Use the Renfert 2D/3D monitor�
• Check, that the Renfert 2D/3D monitor is connected to the
3D port and the additional 2D device is connected to the 2D
port�
• If a 3D display is required on a different monitor, use the
EASY view 3D HDMI Splitter together with a second Renfert
2D/3D monitor (Accessories)�
• Use a full HD capable 2D device�
• Check 2D device settings (e�g: 1080p60)�
• Check settings, consult the 2D device manual if necessary�
100 / 120 / 230 V
FullHD (1920 x 1080)
430 mm [17 inch]
4x / 15x / 20x
615 mm [24�2 inch]
850 mm [33�5 inch]
18 - 74 mm [0�71 - 2�92 inch]
max� 26 mm [1�02 inch]
2�1 kg [4�63 lbs]
0�7 kg [1�54 lbs]
- 23 -
Solution
100 - 240 V
50 / 60 Hz
13�5 W
40,000 lux
5,000 kelvin
4 GB
600
15 minutes�
