Renfert EASY view+3D Original Instructions Manual page 14

Split screen - main menu
The following selections are possible in this menu:
en
• Split screen:
Open split screen sub-menu�
• USB:
Select an image from a USB flash drive and insert it.
• Black & white:
Select which image selection should be displayed in black & white / color�
• Wi-Fi reset:
If available, the Renfert CONNECT Wi-Fi adapter is reset� It is then in access
point mode again and must be reconnected to the Wi-Fi network using the
Renfert APP�
• Exit:
Close the split screen menu�
Sub-menu - split screen
The following selections are possible in this menu:
• Select and insert an image from a USB flash drive.
• Take a screenshot and insert it�
• Settings
- Position of the inserted image�
- Size of the inserted image (3 sizes + full screen)�
- System information
• Switch off split screen function, remove inserted image.
• Exit: Closing split screen menu�
The symbol of the currently selected source of the inserted image (USB flash
drive or screenshot) is displayed in green�
Inserting an image from a USB flash drive
⇒ Select the USB flash drive in the split screen main menu (Fig. 20) or the split
screen sub-menu (Fig� 21)�
⇒ Select using the left mouse button�
♦ A list of the files on the USB flash drive is displayed in the menu.
⇒ Use the mouse wheel to select a file.
♦ A preview of the file is displayed in a corner of the screen.
⇒ Select the desired file using the left mouse button.
♦ The file is inserted and fixed in the opposite corner.
♦ The file name of the selected image is displayed in green.
⇒ Select another file using the mouse wheel or close the file list using the right
mouse button�
Inserting screenshot
⇒ Select the screenshot item in the split screen sub-menu (Fig� 21)�
⇒ Select using the left mouse button�
♦ An hour glass icon appears on the monitor while the screenshot is being
created�
♦ The screenshot taken is inserted into the selected corner of the monitor�
- 14 -
Fig. 19
Fig. 20
Fig. 21
Fig. 22
