G2000e/G3000e/G6000e User's Manual
3. Unwrap the ribbon package and separate the ribbon roll and the spare core.
4. Slide the ribbon roll onto one of the Ribbon Spindles and place the spare core onto the other
spindle, see Figure 2-6.
Figure 2-6 Place Ribbon Roll and Spare Core on Ribbon Spindles
5. Pull the Release Knob of the Ribbon Supply compartment outwards and place the ribbon roll in
the Ribbon Supply compartment, aligning its ends with the Left Mount and the Right Mount
which the Release Knob is attached to. Release the knob to secure the ribbon roll in the Ribbon
Supply compartment, see Figure 2-7.
Figure 2-5 Lift the Printhead Module
Chapter 2: Setup and Use
11
