NTI ENVIROMUX TEMPERATURE/HUMIDITY SENSOR ATTACHMENT

E-STHS-LCDW

The E-STHS-LCDW is a Temperature and Humidity sensor built into a large wall-mount LCD display with 2" character height for

easy viewing from a distance.

template has been provided to make placement and hardware location easy.

be mounted to the sides. These are provided for an alternate method of mounting.

Frontview of E-STHS-LCDW

(Shown without side mounting brackets)

There are two key-hole slots on the back, 4-1/2" apart, for hanging the sensor on the wall. A

2" High

There are also two brackets (with screws) that can

Rearview of E-STHS-LCDW
