17-3 Configuring Communication Parameter

Before trying to transfer data with the ClassPad, you should perform the procedures
described in this section to configure its data communication parameters.
Cla Pad Operation
(1) On the application menu, tap
• This starts the Communication application and displays a window that shows its
current communication parameter settings.
(2) Tap [Setup] and then [Open Setup Menu].
• This displays a dialog box for changing communication parameters, like the one
shown below.
(3) Configure the communication parameter settings as described below.
• Items marked with an asterisk (
Screen Copy To
Specify "Outer Device".
Cable Type
When connecting to thi type of device:
Another ClassPad unit or a Data Analyzer
A computer's USB port
17-3-1
Configuring Communication Parameters
.
) are initial defaults.
*
20060301
Select thi etting:
3pin cable
USB cable*
